Kyocera AVX's dual-row inverted through-board card edge connectors feature staggered contacts that enable four to 12 positions.

Features a BeCu contact system that provides a full 2.5A per contact current rating and low-profile (2.85mm above-board) through-board design supports applications with minimal height constraints on the mating side of the PCB and doesn’t interfere with LEDs. Staggered contact configuration prevents shorting and contact damage when inserting and removing mating PCBs, and is approved to UL1977 safety standards. Is Designed for 1.6mm-thick mating PCBs with gold-plated pads and rated for 2.5A per contact, 300VAC, 10 mating cycles, and operating temperatures extending from -40°C to +125°C. Features white, glass-filled, high-temperature, UL94 V-0 Nylon insulators equipped with 4, 6, 8, 10, or 12 contacts, gold plating on the nose, and lead-free matte tin plating on the tails.

Kyocera AVX

kyocera-avx.com
