DownStream Releases CAM350/DFMStream v. 14.5, BluePrint-PCB v. 6

Published: 17 November 2020

CAM350/DFMStream v. 14.5 and BluePrint-PCB v. 6 now support importation and visualization of CAD designs containing flex, rigid-flex and embedded component data in both 2-D and 3-D views.

Focus on importing and visualizing flex/rigid-flex data created by PCB CAD tools in 2-D and 3-D view ports, as well as documenting rigid/rigid-flex stack-ups; can share documentation with PCB fabricators. Features include import/export ODB++ and IPC 2581 modification; import/export modification to support PCB core material data; stack-up visualizer modification; 3-D view port modification; area tool modification; DFM analysis modification; parametric solder and paste mask generation; assembly panel creation; new documentation objects; output generation.

3D Flex 1

3D Flex 2

DownStream Technologies
downstreamtech.com
