DSG800 Series RF signal generators provide support for internal and external IQ generation to quickly generate IQ traffic to simulate or validate designs.

Come in 2.1GHz and 3.6GHz models. Internal IQ modulation is said to eliminate the need for an external IQ source, simplifying setup, minimizing expense and ensuring system accuracy. Internal IQ waveform construction is supported by free Ultra IQ Station software utility. Non IQ versions also available at 2.1GHz and 3.6GHz for high-performance RF signal generation without IQ. All models deliver maximum output power up to +20dBm and low SSB phase noise of -112dBc/Hz, amplitude accuracy of +/-0.5dB, and frequency resolution 0.01Hz at any frequency. Optional oven-controlled crystal oscillator time-base provides

Rigol Technologies

rigolna.com

Rigol DSG800
