Pulsonix v. 12.0 adds new capabilities, speed improvements and usability enhancements.

Includes 3-D collision detection for multi-board designs and board folding. Allows designers to visualize boards in stacked or folded configuration and verify boards and components fit together in intended space. Automated clash detection flags any space violations. Can ignore clashes intended for known connection points like plugs and sockets. 3-D capabilities are integrated into consolidated 3-D design menu that organizes setup and operation. Has 64-bit implementation and additional multi-threading capabilities. Users with large designs will see increased speed due to increased 64-bit address space and multi-threading for library access; 3-D rendering is now multi-threaded, meaning 3-D viewing and STEP output can be spread across multiple cores and reportedly completed in less than half the time. Includes dark mode option, additional rules and DRC checking. New rules include stub routing length, loop antenna, return path, SMD to corner and SMD to plane rules. Has additional enhancements to edit differential pair tracks.

Pulsonix

Pulsonix
pulsonix.com/latestversion
