Ucamco's UcamX v2024.06 and Integr8tor v2024.06 CAM and pre-CAM software include new additions to increase customers’ productivity.

UcamX v2024.06 now features the ability for a visual check before clipping, get a copper coverage percentage by filling with tracks, and calculate copper areas for all subjobs. Also features ATG Output that supports data sets with up to 150 layers, a new feature to edit contour text, new extended view options, extended Board Analyzer by count of drilled slot, and Gerber X2/X3 output now fully supports layer, aperture and object attributes.

Integr8tor v2024.06 includes extended QED Copper Areas section for Top and Bottom, extended Drill Tools section with a Wall (or barrel surface) area for each tool individually, improved via in pad paste layer analysis, a QED section listing copper clearance information based on layer netlist rather than job netlist, and minimum clearance legend to pad for solder mask-defined pads. Also features checkpoint unit conversion, archive contents exclusion, re-use of incoming ODB++ pad type information, and configurable step names for DPMX import and ODB++ export.

Ucamco

ucamco.com
